5 Megapixel TVI/AHD/CVI, Outdoor Bullet, 60’ White Light Range, D-WDR, 12VDC, Audio Over Coax (AoC)
Features
** With use of Paramont (Version 1.3.8 and above)/ Vision DVRs. TVI Only.
Camera | |
Image Sensor | 1 / 2.5 "CMOS |
Resolution | 5MP/4MP |
Image Size | 2560 x 1936 |
Video Output | AHD / TVI /CVI |
Image System | PAL / NTSC |
Electronic Shutter | Auto |
White Light Distance | Up to 60’ |
Frame Rate | 5MP@20fps/4MP@30fps |
Min. Illumination | Color: [email protected], AGC ON; B/W: 0 lux with IR |
Lens | 3.6 mm |
Lens Mount | M12 |
S / N Ratio | ≥52dB ( AGC OFF ) |
Ingress Protection | IP 67 |
FOV | 79° 63.4° 91.7° |
Audio | |
Audio | Built-in Mic, Audio Over Coax (AoC) |
Camera audio | TVI Support |
Audio Sensitivity | -36db |
Functions | |
Function Control | OSD ( COC Control ) |
Day & Night | ICR |
Digital WDR | Yes |
Digital NR | Yes, 2D DNR |
Global Exposure | Yes |
Central Exposure | No |
AGC | Yes |
Auto White Balance | Yes |
BLC | Yes |
Front Light Compensation | No |
Contrast | Yes |
Sharpness | Yes |
Smart IR | No |
Image Setting | Yes |
Defect Correction | Auto |
Language | Chinese and English |
Angle Adjustment | Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360° |
Others | |
Power Supply | DC12V ( ± 10% ) |
Power Consumption | IR OFF : < 1W; IR ON : <3.5W |
Working Environment | -22°F ~ 122°F (- 30 °C ~ 50 °C), 10 % ~ 90 % (relative humidity) |
Dimensions | 6.6 x 2.9 x 2.9 in (167.5 x 74.5 x 74.5 mm) |
Weight ( net ) | Approx. .8 lb (0.37KG) |
: Junction Box
: Pole Mount (Use with IPM-JB6)
: Corner Mount (Use with IPM-JB6)
PAR-C5BIR36AWL: 5 Megapixel Outdoor Bullet, 3.6mm
