Archived:
16-ch H.264/MPEG4/MPEG2/MJPEG Video Encoder
FeaturesModel Number | ULT-TVIENCODER16 |
Video Compression | H.264 / MPEG4 / MPEG2 / MJPEG |
Video input | 16-ch, BNC @ up to 1080p/30fsps |
Audio Compression | G.711u |
Audio input | 4-ch RCA (2.0 Vp-p, 1 KΩ) |
Two-way audio input | 1-ch |
Audio output | 1-ch RCA (Linear, 1 KΩ) |
Recording resolution | 1080P/720P/WD1/4CIF/VGA/CIF |
Frame rate | 1/16 fps to real time frame rate |
Video bit rate | 32 Kbps ~ 10 Mbps |
Audio bit rate | 64 Kbps |
Dual-stream | Support |
Stream type | Video, Video & Audio |
Type | NAS, iSCSI, IPSAN |
Capacity | 2 internal SATA up to 8TB ea. |
Network interface | 1 RJ-45 10M/100 Mbps adaptive Ethernet interface (PoE) |
Protocols | IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-11), DNS, DynDNS, hkDDNS, NTP, RTSP, RTP/RTCP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SOCKSv4/v5, PSIA, OnVIF, Hik CGI, netFilter |
Serial interface | 1 half-duplex RS-485 interface |
Alarm in | 8 |
Alarm out | 4 |
Power supply | 12 VDC |
Consumption | ≤ 30W |
Working temperature | 14°F ~ 131°F (-10 °C ~ +55 °C) |
Working humidity | 10% ~ 90% |
Dimensions (W x D X H) | 14.96″ × 11.42″ × 1.89″ |
Weight | 4.41 Lbs |
ULT-TVIENCODER16: 16-ch Video Encoder
