System

PN1A-16X16-2NH2

OS

Embedded Linux

Video

Network Input

16CH IPC input

Network Input Resolution

8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/

960H/D1/CIF

Output

HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024/ 1024 × 768
VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768

Screen Display Mode

1/4/6/8/9/13/16

Compression

H.265S /H.265+ / H.265 / H.264

Audio

Network Input

16 CH IPC audio input

Local Input

RCA × 1 (for two-way audio)

Local Output

RCA × 1

Compression

G.711(U/A)

Record

Resolution

8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/

960H/D1/CIF

Frame Rate

NTSC:30fps; PAL:25fps

Playback

Simultaneous Playback

Max.16 CH

Search

Time slice / time / event / tag / smart search

Smart Search

Highlighted color to display the camera record in a certain period of time, different colors refers to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Decoding Capability

Live View/ Playback

1×8MP@30fps; 6×1080P@30fps

Alarm

Mode

Manual, sensor, motion, exception, smart events

Input

Supports IPC alarm input

Output

Supports IPC alarm output

Triggering

Record, snap, preset, e-mail, etc.

Network

Interface

RJ 45 × 1 (10/100/1000Mbps)

Protocol

TCP / IP, IPv4, IPv6, UDP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, HTTP, SMTP, HTTPs, 802.1x, RTSP, RTP, RTCP, WebSocket, SNMP, IGMP, ONVIF

Incoming/ Outgoing Bandwidth

160/160(Mbps) *When the AI function of the IPC is enabled, the actual incoming bandwidth(max.bitrate) is more than the set value in the NVR.

Client Connection

Max. 64 users access

Face

Face Detection

Performance (AI by IPC)

16 CH (NH-AI Models)

Face Detection Performance

(AI by Device ONVIF)

2 CH/ 2MP

Face Match Performance

No (Does NOT Support Facial Recognition)

Statistical Graph of Information

Bar graph

Statistical Mode of Information

Statistics by day, week, month, quarter as well as customized time period

Video Structure Analysis

Human/Vehicle Classification
(AI by IPC)

Up to 16 CH

Human/Vehicle Classification
(AI by Device)

2 CH

Human/Vehicle Attribute Analysis

Yes (AI by IPC)

Other Functions

Fisheye

Supports fisheye dewarping via Web Client and mobile APP

Plate Recognition (AI by IPC)

Up to 16 CH

Mobile Device

OS

iOS, Andriod

Storage

HDD Interface

SATA3.0 × 2, up to 18TB

Backup

Local Backup

USB, USB To HDD (1TB Max)

Network Backup

Yes

Port

USB

USB 2.0 × 2, USB to

Remote Controller

Included

PoE

PoE Ports

100M RJ45 × 16

Standards

IEEE802.3AF/AT

Output Power

≤ 150W

Others

Power Supply

DC 48V/3.75A

Consumption

≤ 10W ( without HDD )

Dimensions ( W × D × H )

15 x 10.6  x 1.8In (380 × 268 × 45 mm)

Working Environment

14°F  ~ 122°F (-10°C ~ 50°C)10% ~ 90% humidity

Certificate

CE, FCC, ETL: 5025761

Environmental Protection

Complies with Directive EU RoHS, REACH and WEEE
